WF1271-2WMHXXBX1
Wire To Board Connector,Plug,Vertical SMT,Surface Mount,Double Row,Black
Quick Inquiry
2D Drawing(PDF)
Packaging Specification
| Rated Voltage | 50 V/AC,V/DC | Operation Temperature | -40°C - +105°C | |
| Rated Current | 1 AMP | Contact Material | Copper Alloy | |
| Contact Resistance | 30 mΩ Max | Insulator Material | Thermoplastic Plastics | |
| Insulation Resistance | 1000 MΩ Min | Contact Plating | Au | |
| Withstand Voltage | 250 V/DC,V/AC | Packaging | Tube,Reel | |
RoHS
Compliant
REACH
Compliant
